How to Install
NOTICE
All D enclosures are available with standard input terminals or disconnect switch. All terminal dimensions can be found
in Table 3.7.
IP21 (NEMA 1)/IP54 (NEMA 12)
D1 D2
A 277 (10.9) 379 (14.9)
B 227 (8.9) 326 (12.8)
C 173 (6.8) 273 (10.8)
D 179 (7.0) 279 (11.0)
E 370 (14.6) 370 (14.6)
F 300 (11.8) 300 (11.8)
G 222 (8.7) 226 (8.9)
H 139 (5.4) 142 (5.6)
I 55 (2.2) 59 (2.3)
J 354 (13.9) 361 (14.2)
K 284 (11.2) 277 (10.9)
L 334 (13.1) 334 (13.1)
M 250 (9.8) 250 (9.8)
N 167 (6.6) 167 (6.6)
O 261 (10.3) 260 (10.3)
P 170 (6.7) 169 (6.7)
Q 120 (4.7) 120 (4.7)
R 256 (10.1) 350 (13.8)
S 308 (12.1) 332 (13.0)
T 252 (9.9) 262 (10.3)
U 196 (7.7) 192 (7.6)
V 260 (10.2) 273 (10.7)
Table 3.7 Cable Positions Dimensions in mm (inch)
VLT AQUA Drive FC 202 Operation Instructions
IP00/Chassis
D3 D4
119 (4.7) 122 (4.8)
68 (2.7) 68 (2.7)
15 (0.6) 16 (0.6)
20.7 (0.8) 22 (0.8)
363 (14.3) 363 (14.3)
293 (11.5) 293 (11.5)
215 (8.4) 218 (8.6)
131 (5.2) 135 (5.3)
48 (1.9) 51 (2.0)
347 (13.6) 354 (13.9)
277 (10.9) 270 (10.6)
326 (12.8) 326 (12.8)
243 (9.6) 243 (9.6)
159 (6.3) 159 (6.3)
261 (10.3) 261 (10.3)
170 (6.7) 170 (6.7)
120 (4.7) 120 (4.7)
98 (3.8) 93 (3.7)
301 (11.8) 324 (12.8)
245 (9.6) 255 (10.0)
189 (7.4) 185 (7.3)
260 (10.2) 273 (10.7)
