0-22 Display Line 1.3 Small
Option:
[1614] Motor
*
Current
0-23 Display Line 2 Large
Option:
[1615] Frequency The options are the same as those listed for
*
5 5
0-24 Display Line 3 Large
Option:
[1652] Feedback [Unit] The options are the same as those
*
0-37 Display Text 1
Range:
0 [0 -
*
25 ]
0-38 Display Text 2
Range:
0 [0 -
*
25 ]
0-39 Display Text 3
Range:
0 [0 -
*
25 ]
88
Function:
Select a variable for display in line 1,
right position.
The options are the same as those listed
for 0-20 Display Line 1.1 Small.
Function:
Select a variable for display in line 2.
par. 0-20 Display Line 1.1 Small
Function:
listed for 0-20 Display Line 1.1 Small.
Select a variable for display in line 2.
Function:
In this parameter it is possible to write an
individual text string for display in the LCP or to be
read via serial communication. If to be displayed
permanently select Display Text 1 in 0-20 Display
Line 1.1 Small, 0-21 Display Line 1.2 Small,
0-22 Display Line 1.3 Small, 0-23 Display Line 2 Large
or 0-24 Display Line 3 Large. Press [
◀
change a character. Press [ ] and [
cursor. When a character is highlighted, it can be
▲ ▼
changed. Press [ ] or [ ] to change a character. A
character can be inserted by placing the cursor
between 2 characters and pressing [
Function:
In this parameter it is possible to write an
individual text string for display in the LCP or to be
read via serial communication. If to be displayed
permanently select Display Text 2 in 0-20 Display
Line 1.1 Small, 0-21 Display Line 1.2 Small,
0-22 Display Line 1.3 Small, 0-23 Display Line 2 Large
or 0-24 Display Line 3 Large. Press [
◀
change a character. Press [ ] and [
cursor. When a character is highlighted by the
cursor, this character can be changed. A character
can be inserted by placing the cursor between two
▲ ▼
characters and pressing [ ] or [
Function:
In this parameter it is possible to write an
individual text string for display in the LCP or to be
read via serial communication. If to be displayed
permanently select Display Text 3 in 0-20 Display
VLT AQUA Drive FC 202 Operation Instructions
0-39 Display Text 3
Range:
0-70 Date and Time
Range:
Size
related
*
0-71 Date Format
Option:
[0] YYYY-MM-DD
[1] DD-MM-YYYY
[2] MM/DD/YYYY
0-72 Time Format
Option:
▲ ▼
] or [ ] to
▶
] to move the
[0] 24 h
[1] 12 h
0-74 DST/Summertime
▲ ▼
] or [ ].
Option:
[0] Off
[2] Manual
0-76 DST/Summertime Start
▲ ▼
] or [ ] to
Range:
▶
] to move the
Size related
].
0-77 DST/Summertime End
Range:
Size related
MG20P402 - Rev. 2013-12-16
Function:
Line 1.1 Small, 0-21 Display Line 1.2 Small,
0-22 Display Line 1.3 Small, 0-23 Display Line 2 Large
or 0-24 Display Line 3 Large. Press [
◀
change a character. Press [ ] and [
cursor. When a character is highlighted by the
cursor, this character can be changed. A character
can be inserted by placing the cursor between 2
▲
characters and pressing [ ] or [
Function:
[ 0 - 0 ] Sets the date and time of the internal
clock. The format to be used is set in
0-71 Date Format and parameter 0-72 Time
Format.
Function:
Sets the date format to be used in the LCP.
Sets the date format to be used in the LCP.
Sets the date format to be used in the LCP.
Function:
Sets the time format to be used in the LCP.
Function:
Choose how Daylight Saving Time/Summertime
should be handled. For manual DST/Summertime
enter the start date and end date in
parameter 0-76 DST/Summertime Start and
parameter 0-77 DST/Summertime End.
Function:
[ 0 - 0 ] Sets the date and time when
*
summertime/DST starts. The date is
programmed in the format selected in
0-71 Date Format.
Function:
[ 0 - 0 ] Sets the date and time when
*
summertime/DST ends. The date is
programmed in the format selected in
0-71 Date Format.
▲ ▼
] or [ ] to
▶
] to move the
▼
].
