5.3.2. Ethernet

NB2800 routers ship with 2 dedicated Gigabit Ethernet ports (ETH1 and ETH2) and an addi-
tional extension port which can be linked via RJ45 connectors.
ETH1 usually forms the LAN1 interface which should be used for LAN purposes. Other inter-
faces can be used to connect other LAN segments or for con guring a WAN link. The LAN10
interface will be available as soon as a pre-con gured USB Ethernet device has been plugged
in.
Ethernet Port Assignment
Figure 5.6.: Ethernet Ports
This menu can be used to individually assign each Ethernet port to a LAN interface, just in
case you want to have different subnets per port or use one port as WAN interface. You may
assign multiple ports to the same interface.
