The Digital Output signal have the following speci cation:
Feature
Number of ports
Max. continuous output current
Max. switching output voltage
Max. switching capacity
Pin Signal
1 Line IN +
2 Line IN
3 Digital IN +
4 Digital OUT +
5 Digital OUT
6 Digital IN
7 Line OUT +
8 Line OUT
Table 3.32.: Pin Assignments of RJ45 Audio-PTT Connector
NB2800 User Manual 4.2
Speci cation
1x Digital Out (NO)
1A
60 V , 42 V
DC
60W
Table 3.31.: Digital Output Speci cation
26
( V )
AC rms
