3.6.2. Mobile

The various variants of the NB2800support multiple multimode modules for mobile com-
munication.
Standard
4G (LTE/FDD)
3G (DC-HSPA+/UMTS)
2G (EDGE/GPRS/GSM) B9(900), B3(1800), B2(1900)
LTE450
CDMA450
LTE Advanced Cat. 6
Note: This enumeration is not meant to be exhaustive.
The LTE modules support 2x2 MIMO.
The mobile antenna ports have the following speci cation:
Feature
Max. allowed cable length
Max. allowed antenna gain
including cable attenuation
Min. distance between collocated
radio transmitter antennas
Min. distance between people and
antenna
Connector type
NB2800 User Manual 4.2
Bands
B1(2100), B2(1900), B3(1800), B5(850),
B7(2600), B8(900), B20(800)
B5(850), B8(900), B2(1900), B1(2100)
LTE Band 3 (1800 MHz), LTE Band 7
(2600 MHz), LTE Band 20 (800 MHz),
LTE Band 31 (450 MHz), UMTS Band 1
(2100 MHz), UMTS Band 8 (900 MHz)
Band Class 5 Block Designators A + B
B30 (2300 WCS), B41 (TDD 2500), B29
(US 700de Lower), B26 (US 850 Ext), B25
(1900), B5 (850), B20 (800DD), B13 (700c),
B12 (700ac), B7 (2600), B4 (AWS), B3
(1800), B2 (1900), B1 (2100)
Table 3.5.: Mobile Interface
Speci cation
30 m
2.5 dBi
20 cm
40 cm
Option Jf: FAKRA (Standard)
Option Js: SMA
Table 3.6.: Mobile Antenna Port Speci cation
13
Data rate
Downlink: 100 Mbit/s
Uplink: 50 Mbit/s
Downlink: 42 Mbit/s
Uplink: 5.76 Mbit/s
Downlink: 236.8 kbit/s
Uplink: 236.8 kbit/s
Downlink: 100 Mbit/s
Uplink: 50 Mbit/s
Downlink: 14.7 Mbit/s
Uplink: 5.4 Mbit/s
Downlink: 300 Mbit/s
Uplink: 50 Mbit/s
