5.3.7. Serial Port

This page can be used to manage your serial ports. A serial port can be used by:
Parameter
none
login console
device server
modem bridge
modem emulator
SDK
NB2800 User Manual 4.2
Serial Port Usage
The serial port is not used
The serial port is used to open a console which can be accessed
with a serial terminal client from the other side. It will provide
helpful bootup and kernel messages and spawns a login shell,
so that users can login to the system.
The serial port will be exposed over a TCP/IP port and can be
used to implement a Serial/IP gateway.
Bridges the Serial Interface to the Modem TTY of an inter-
grated WWAN Modem.
Emulates a classical AT command driven modem on the se-
http://wiki.netmodule.com/app-notes/
rial interface. See
hayes-modem-at-simulator
The serial port will be reserved for SDK scripts.
Figure 5.17.: Serial Port Administration
68
for detailed information.
