3.6. LED Indicators

The following table describes the NB2800 status indicators.
Label Color
STAT blinking
[1]
MOB1
blinking
[1]
MOB2
blinking
VPN
[1]
WLAN1
blinking
[1]
WLAN2
blinking
NB2800 User Manual 4.2
Panel Function
Rear 2 FAKRA coding I/D jacks for MIMO WLAN 2 or MIMO LTE
antenna
Rear Auxiliary port
Rear 2 FAKRA coding I/D jacks for MIMO WLAN or MIMO LTE
antenna
Rear Audio/CAN/IBIS/RS-232/RS-485/Audio-PTT extension.
Table 3.2.: NB2800 Interfaces
State Function
The device is busy due to startup, software or con gura-
tion update.
on The device is ready. The captions of the top bank apply.
on The device is ready. The captions of the bottom bank ap-
ply.
on Mobile connection 1 is up.
Mobile connection 1 is being established.
off Mobile connection 1 is down.
on Mobile connection 2 is up.
Mobile connection 2 is being established.
off Mobile connection 2 is down.
on VPN connection is up.
off VPN connection is down.
on WLAN 1 connection is up.
WLAN 1 connection is being established.
off WLAN 1 connection is down.
on WLAN 2 connection is up.
WLAN 2 connection is being established.
off WLAN 2 connection is down.
