Direct Drive TURBO

1
8

Fan Parts List

®

Fan

13
2
3
4
5
6
7
Item Description
1* Shutter (plastic)
Shutter (aluminum)
2 Cast Aluminum Blade
3 Fiberglass Shroud
4 Fan Upper Motor Mount
5 Motor
6 Danger Decal
7 Lower Motor Mount
8 Identification Decal
9 Shroud Grill
10 Taper Lock Hub
11 Plastic Outlet Cone
12 Cone Grill
13 1/4-20 x 7/8 Wafer Head Bolt
14 Nylon Washer
15 1/4-20 SS Hex Ser. Flange Nut 46298
16 1/4 x 1-3/4 SS Lag Screw
17 Shutter Clip
Notes: * See page 12 for part numbers.
TM
TURBO Fiberglass Cone and Grill Fan—36" Direct Drive
15
17
16
9
10
Part No.
38027
38259
38902
37913
37738
*
2527-52
37739
—
37920
38907
38267
35228
40775
4856
40938
36729
14
12
11
13
