Fan Parts Listing - Chore-Time Turbo Installation & Operator's Instruction Manual

Fiberglass Turbo
3
4
1
2
15
Item Description
1 Shutter Pivot Rod
2 Shutter Louver
3 Shutter
4 Fiberglass Housing
5 Motor
6 Upper Motor Mount
7 Fan Blade
8 Fan Cone
9 Expanding Bushing 1/2"
10 Fan Grill
11 Weather Cover
12 Weather Cover Guard
13 Lower Motor Mount
14 Danger Decal
15 Winter Shutter Insert (Optional)

Fan Parts Listing

®
5
6
7
13
14
MV1517-9 3/98
14"
Part No. Part No.
38702-8 38702-7
38038-8 38038-7
40604
40437
7296
40456
40673
40459
40674
40460
7442
7374
40455
2527-50 2527-50
41141-1 41141-2
14, 18, and 24 Fiberglass Turbo
9
10
8
60 Hz
18" 24" 18"
Part No. Part No.
38702-9 38702-7
38038-9 38038-7
40603 40602 40603
40324 40177 40324
7034 33893 7034
40439 40123 40439
40672 40671 40672
40441 40179 40441
40674 40674 40674
40442 35338 40442
6948 6950 6948
7440 7009 7440
40440 40124 40440
2527-50 2527-50
41141-3 41141-2
®
Fans
11
12
50 Hz
24"
Part No.
38702-9
38038-9
40602
40177
3005
40123
4146
40179
-
35338
6950
7009
40124
2527-50
41141-3
15
