36" Belt Drive Panel Fan Parts List

Item Description
1 36" Fan Shroud
2* Post (L.H.)
3 V-Belt
4 Fan Blade
5* Post (R.H.)
6 Front Wire Screen
7 Danger Decal
8 Danger Decal
9* "L" Bracket
10 Motor Support
11 Pulley
12 Motor
36" Belt Drive
Panel Fan
Assembly
27150LM
27150
27150-50HZ
27150-3PH
36" Belt Drive Panel Fan Installation Manual
Part No.
5538
27153-2
1322
29736
27153-1
7687
2527-50
2527-10
27163
27155
See Chart
See Chart
Motor Specifications
H.P. Hz. Phase
-- -- --
1/2 60 1
1/2 50 1
1/2 60 3
• Page 8
Item Description
13* Flangette
14* Bearing Assembly
15* Bearing Mount Assembly
16* Pulley
17 Bar Washer
18* 3/16" Sq. x 1.00" Key
19* Shaft
20 Rear Wire Screen
*These items may be ordered as a Post
Assembly under Chore-Time Part No. 29315.
Motor
Voltage
Part No.
-- --
115/230 8304
220 8304-50HZ
230/460 4714
Part No.
20192-1
20192-5
8197
27737
27170
2112-1
27164
27157
Motor Pulley
Part No.
- -
4906
8773
4906
