MBT-5000 L-Band Up/Down Converter System
Appendix A
A.3
Module Installation Procedure
Step
Task
Re-install the module:
First, take care to ensure the Teflon guide ramp is
properly engaged with the module.
1
Then, use the front thumb tabs on the module to
slide the module into a position that allows re-
installation of the Reference and Ribbon Cables.
A–5
MN-MBT5000
Revision 4
