MBT-5000 L-Band Up/Down Converter System
Front Panel Operation
Use the ◄ ► arrow keys to first select the digit to edit, and then use the ▼▲ arrow keys to edit
the value of that digit.
Note the following:
•
The valid range for this parameter is from the unit's specific P1dB power level to P1dB minus
19 dB.
For example: For a unit with +12 dBm at P1dB, the range would be +12.0 to -7 dBm.
•
The default value is -20.0 dBm. Setting the parameter to this default value effectively
disables the threshold.
•
If Power Monitoring is not supported, and you select ConvA or ConvB, the following
message displays:
This Converter Does NOT
Support Power Monitor.
Press ENTER when done or CLEAR to return to the previous menu.
5–15
MN-MBT5000
Revision 4
