MBT-5000 L-Band Up/Down Converter System
Serial-based Remote Product Management
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier)
IP Address IPA= 18 bytes
Gateway IPG= 15 bytes
Address
Initialize ISP= None
Statistics
Pointer
Local/Remote LRS= 1 byte
State
Unit MAC N/A 17 bytes
Address
(Note that all arguments are ASCII numeric codes between 48 and 57)
Query
Command or Query.
Sets the IP address and network prefix for the 10/100 BaseT Ethernet management port, in the
form xxx.xxx.xxx.xxx.yy, where:
xxx.xxx.xxx.xxx is the IP address, and
yy is the network prefix (8-30)
Default Value: 192.168.001.004.24
Example: IPA=192.168.001.004.24
Command or Query.
Sets the Gateway IP address for the 10/100 Base Tx Ethernet management port, in the form:
xxx.xxx.xxx.xxx, where:
xxx.xxx.xxx.xxx is the IP address
Default Value: 192.168.001.005
Example: IPG = 192.168.001.005
Command only.
Resets internal pointer to allow RNS? Queries to start at the beginning of the stored statistics
log.
Example: ISP=
Command or Query.
Set Local or Remote
0 = Local, 1=Serial, 2=Ethernet
Default value: 0
Example: LRS=1
Note: The customer will always have query access in either mode. Also, the LRS command is
available in all modes as a means of acquiring control. The intent of this command is to limit
changes from being made on multiple interfaces at the same time.
Query only.
MAC address of the unit, reported in hexadecimal.
Example: MAC=00-06-B0-00-D2-A7
Description of Arguments
7–12
MN-MBT5000
Revision 4
Response to Query
Response to query
Command (Instruction
(Target to Code and
Controller) Qualifier)
IPA= IPA? IPA=
IPA? xx.xxx.xxx.xxx.yy
IPA*
IPA# (See Description of
Arguments)
IPG= IPG? IPG = xxx.xxx.xxx.xxx
IPG?
IPG*
ISP= N/A N/A
ISP?
ISP*
LRS= LRS? LRS=x
LRS?
(Same format as
Command
arguments)
MAC= MAC? MAC=xx-xx-xx-xx-xx-
MAC* xx
(See Description of
Arguments)
(Target to
Controller)
