Installation

3 Installation

3.1 Mechanical Installation

Select the best possible operation site by considering:
•
Ambient operating temperature
3 3
•
Installation method
•
How to cool the unit
•
Position of the frequency converter
•
Cable routing
•
Power source supplying correct voltage and
necessary current
•
Motor current rating within the maximum current
from the frequency converter
•
Correct rating of external fuses and circuit
breakers
Cooling and Mounting:
•
Top and bottom clearance for air cooling must be
provided, see Table 3.1 for clearance requirements
•
Derating for temperatures starting from 45 °C
and elevation 1000 m above sea level must be
considered. See the equipment Design Guide for
detailed information.
Enclosure
Clearance above and below the
unit [mm]
Table 3.1 Minimum Airflow Clearance Requirements
•
Mount the unit vertically
•
IP20 units (but NOT IP21 units) allow side-by-side
installation
•
Improper mounting can result in over heating
and reduced performance
•
Use the slotted mounting holes on the unit for
wall mounting, when provided
•
See 8.4 Connection Tightening Torques for proper
tightening specifications.
10
®
VLT AutomationDrive FC 360 Quick Guide
J1-J5 J6/J7
100 100-200
®
