Installation
1
3 3
9
Illustration 3.2 Typical Electrical Connection
1 PLC
2 Frequency converter
3 Output contactor (Generally not recommended)
4 Earth (grounding) rail (PE)
5 Cable insulation (stripped)
Table 3.2 Legend to Illustration 3.2
12
VLT
10
L1
L2
L3
PE
MG06A302 - VLT
®
AutomationDrive FC 360 Quick Guide
2
Status Quick Main
Menu Menu
Menu
OK
Hand Auto
On Reset On
8
6 Min. 200 mm (7.9 in) between control cables, motor and mains
7 Motor, 3-phase and PE
8 Mains, 3-phase and reinforced PE
9 Control wiring
10
Equalising min. 16 mm
®
is a registered Danfoss trademark
3
4
6
7
2
(0.025 in)
5
U
V
W
PE
