A-6
Appendix A: Module Specifications
Environmental Tests
ESD immunity
(Performance Criteria B)
Radiated RF immunity
(Performance Criteria A)
EFT/B immunity
(Performance Criteria B)
Surge transient immunity
(Performance Criteria B)
Conducted RF immunity
(Performance Criteria A)
Magnetic Field
(Performance Criteria A)
AC Mains Voltage Dips,
Interruptions and
Variations
User's Manual Pub. 0300266-02 Rev. B
Industry Standards
IEC 61000-4-2
IEC 61000-4-3: Level 3
IEC 61000-4-4*
IEC 61000-4-5
IEC 61000-4-6
IEC 61000-4-8
IEC 61000-4-11
Test Level Limits
6 kV Indirect (Coupling Plate)
6 kV Contact Discharge (to points of
initial contact)
8 kV Air Discharge (to points of initial
contact)
10 V/M with 1 kHz sine-wave 80% AM
from 80 MHz to 2000 MHz
10 V/M with 200 Hz sine-wave 50%
Pulse 100% AM at 900 MHz
10 V/M with 200 Hz sine-wave 50%
Pulse 100% AM at 1890 MHz
1 V/M with 1 kHz sine-wave 80% AM
from 2000 MHz to 2700 MHz
(3 V/M goal)
Signal Ports:
±3 kV at 5 kHz for 5 minutes, Criteria
B
±2 kV at 5 kHz for 5 minutes, Criteria
A
±2 kV at 5 kHz for 5 minutes, Criteria
B (standard)
Power Ports:
±2 kV at 5 kHz for 5 minutes, Criteria
A
±2 kV at 5 kHz for 5 minutes, Criteria
B (standard)
Signal Ports:
±2 kV line-earth {CM}at 2 Ω on
shielded ports
Power Ports
±2 kV CM at 12 Ω
±1 kV DM at 2 Ω
10 VRMS with 1 kHz sine wave 80%
AM from 150 kHz to 80 MHz on signal
and power ports
30 Arms/m
Follow the 61000-4-11.
