Chapter 3: Configuring the 1734sc-IF4U for RSLogix 5000

3.3.2 Add a Remote Ethernet Point IO Adapter

After you have added the local Ethernet communication module, you must add
remote Ethernet communication modules. A remote Ethernet module is a module
that resides in a separate chassis from the controller.
If you plan to use the 1734 Control Net adapter, you will need to install
NOTE
the 1734sc-IF4U EDS file before scheduling the network. The latest EDS
files can be found at (www.spectrumcontrols.com).
1. Select a New Module for the I/O Configuration:
Right-click on the local
communication module
User's Manual Pub. 0300266-02 Rev. B
3-5
Select New Module
