3-14
Chapter 3: Configuring the 1734sc-IF4U for RSLogix 5000
User's Manual Pub. 0300266-02 Rev. B
circuit or short-circuit condition is detected. Default setting is upscale.
Response Option Definition
Upscale
Sets the input data value to full-scale value. The full-scale
value is determined by the selected input type and data
format.
Downscale
Sets the input data value to minimum-scale value. The
minimum-scale value is determined by the selected input
type and data format.
Zero
Sets the input data value to zero (0).
Input Type (Bits 6 through 10)
These bits specify the input type for each channel. If channel 0 or 2 is configured
for multi-wire RTD, the configuration for the adjacent odd channel (1, 3) is
ignored. It is recommended to configure both channels identically (0 and 1, 2,
and 3) when using multi-wire RTD. This reduces confusion in the setup. A zero
will be reported for the adjacent odd channel in multi-wire RTD. The ±10 V
range is the default input type for each IF4U channel.
Data Format (Bits 11 and 12)
Data Format dictates how the data is presented. Engineering Units ×1 is the
default.
Table 3-3. Data Formats
Input Range
Input Value
1000.00 °C
1000.00 °C
E Type TC
-270.00 °C
-270.00 °C
1200.00 °C
1200.00 °C
J Type TC
-210.00 °C
-210.00 °C
1370.00 °C
1370.00 °C
K Type TC
-270.00 °C
-270.00 °C
400.00 °C
400.00 °C
T Type TC
-270.00 °C
-270.00 °C
850.00 °C
RTD
850.00 °C
100 Ohm Pt 0.385
-200.00 °C
-200.00 °C
850.00 °C
RTD
1000 Ohm Pt 0.385
850.00 °C
Condition
EU ×1
EU ×10
High Limit
10000
1000
High Range
10000
1000
Low Range
-2700
-270
Low Limit
-2700
-270
High Limit
12000
1200
High Range
12000
1200
Low Range
-2100
-210
Low Limit
-2100
-210
High Limit
13700
1370
High Range
13700
1370
Low Range
-2700
-270
Low Limit
-2700
-270
High Limit
4000
400
High Range
4000
400
Low Range
-2700
-270
Low Limit
-2700
-270
High Limit
8500
850
High Range
8500
850
Low Range
-2000
-200
Low Limit
-2000
-200
High Limit
8500
850
High Range
8500
850
Raw Prop
PID
32767
16383
32767
16383
-32768
0
-32768
0
32767
16383
32767
16383
-32768
0
-32768
0
32767
16383
32767
16383
-32768
0
-32768
0
32767
16383
32767
16383
-32768
0
-32768
0
32767
16383
32767
16383
-32768
0
-32768
0
32767
16383
32767
16383
