A-4 Appendix A: Module Specifications
Input
Current Inputs
IF4U
RTD Inputs
IF4U
Resistance Inputs
Device or Range
Type J
Type K (-200 ºC to 1370 ºC)
Type K (-270 ºC to -200 ºC)
Type T (-190 ºC to 400 ºC)
Type T (-270 ºC to -190 ºC)
Type E (-200 ºC to 1000 ºC)
Type E (-270º C to -200 ºC)
±50 mV
±100 mV
±10 V
±1 V
0-5 V
1-5 V
0-10 V
7
These filters do not reject 50/60 Hz. Repeatability for these filters is strongly dependent on how much 50/60 Hz noise is in the
system.
User's Manual Pub. 0300266-02 Rev. B
Specification
System accuracy at 25 ºC (Using 4 Hz and 17 Hz filters)
±20 µA maximum for 0-20 mA inputs
±20 µA maximum for 4-20 mA inputs
System accuracy at 0 °C to 55 ºC (Using 4 Hz and 17 Hz filters)
±50 µA maximum for 0-20 mA inputs
±50 µA maximum for 4-20 mA inputs
System accuracy at 25 ºC (Using 4 Hz and 17 Hz filters)
±0.5 ºC for 1000 Ω Platinum 385 and 3916
±0.8 ºC for 100 Ω Platinum 385 and 3916
System accuracy at 0° to 55 ºC (Using 4 Hz and 17 Hz filters)
±0.9 ºC for 1000 Ω Platinum 385 and 3916
±1.2 ºC for 100 Ω Platinum 385 and 3916
System accuracy at 25 ºC (Using 4 Hz and 17 Hz filters)
±1 Ω for 3000 Ω range
System accuracy at 0 to 55 ºC (Using 4 Hz and 17 Hz filters)
±3 Ω for 3000 Ω range
Repeatability at 25 ºC
4 Hz Filter
±0.2 ºC
±0.2 ºC
±2 ºC
±0.2 ºC
±1 ºC
±0.2 ºC
±1 ºC
2.5 µV
4.6 µV
0.48 mV
±10 mV
±10 mV
±10 mV
±20 mV
62 Hz and 470 Hz
17 Hz Filter
Filters
±0.4 ºC
±0.4 ºC
±3.5 ºC
±0.4 ºC
±1.5 ºC
±0.4 ºC
±1.5 ºC
3.2 µV
6.4 µV
0.48 mV
±1 mV
±10 mV
±10 mV
±20 mV
7
±2 ºC
±4 ºC
±25 ºC
±4 ºC
±20 ºC
±4 ºC
±20 ºC
70 µV
60 µV
2 mV
±3 mV
±30 mV
±30 mV
±60 mV
