CAPA313 3.5" Board
2.4.1

SMBus Connector (CN1)

This is a 3-pin (pitch=2.0mm) wafer connector which is compliant with JST
B4B-PH-SM3-TB. The SMBus (System Management Bus) is a simple bus for the
purpose of lightweight communication.
Pin
1
2
3
2.4.2

Audio Connector (CN2)

This is a 10-pin (pitch=1.25mm) wafer connector, which is compliant with Molex
53047-1010, for audio interface.
Pin Signal
1 MIC_IN
3 LINE_IN_L
5 LINE_IN_R
7 AUDIO_OUT_L
9 AUDIO_OUT_R
2.4.3

Digital I/O Connector (CN4)

This is a 2x5-pin (pitch=2.0mm) connector. The board is equipped with an 8-bit (4 inputs
and 4 outputs) digital I/O that meets requirements for a system customary automation
control. The digital I/O can be configured to control cash drawers and sense warning
signals from an Uninterrupted Power System (UPS), or perform store security control.
You may use software programming to control these digital signals, please refer to
Appendix B.
Pin Signal
1 Digital Input 1
3 Digital Input 2
5 Digital Input 3
7 Digital Input 4
9 +5V
2
2.4.4 I

C Connector (CN5)

This is a 3-pin (pitch=1.25mm) connector, which is compliant with Molex 530470310, for
2
I C interface.
Pin
1
2
3
12
Signal
SMBus clock
SMBus data
GND
Pin Signal
2 GND
4 GND
6 GND
8 GND
10 GND
Pin Signal
2 Digital Output 8
4 Digital Output 7
6 Digital Output 6
8 Digital Output 5
10 GND
Signal
2
I C_CLK_SBY
2
I C_DAT_SBY
GND
1
1
Board and Pin Assignments
