2.4

Connectors

Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table of connectors on the hardware.
Connector
CN1
CN2
CN4
CN5
CN6
CN7 (Optional)
CN8
CN9
CN10
CN11
CN12
CN13
CN14
CN16
CN17~CN18
CN20
CN21
CN22 (Optional)
ATX1
SCN1, SCN3
SCN2
SDIMM1
Board and Pin Assignments
Description
SMBus Connector
Audio Connector
Digital I/O Connector
2
I C Connector
COM2 Wafer Connector
COM1 Wafer Connector
Fan Connector
SATA Power Connector
USB 2.0 Wafer Port 5 and 6
SATA Connector
Front Panel Connector
LVDS Connector
Inverter Connector
Ethernet Port 1 and 2
USB 3.0 Port 0~3
COM1 D-Sub Connector
HDMI Connector
VGA Connector
ATX Power Connector
Full-size PCI-Express Mini Card Connectors
ZIO Expansion Connector
DDR3L SO-DIMM Connector
CAPA313 3.5" Board
11
