6.4. P-00 Read Only Status Parameters
Description
Par.
P00-01
1st Analog input value (%)
P00-02
2nd Analog input value (%)
P00-03
Speed reference input (Hz / RPM)
P00-04
Digital input status
P00-05
User PI output (%)
P00-06
DC bus ripple (V)
P00-07
Applied motor voltage (V)
P00-08
DC bus voltage (V)
P00-09
Heatsink temperature (˚C)
P00-10
Run time since date of manuf. (Hours)
P00-11
Run time since last trip (1) (Hours)
P00-12
Run time since last trip (2) (Hours)
P00-13
Trip Log
P00-14
Run time since last disable (Hours)
P00-15
DC bus voltage log (V)
P00-16
Heatsink temperature log (˚C)
P00-17
Motor current log (A)
P00-18
DC bus ripple log (V)
P00-19
Internal drive temperature log (˚C)
P00-20
Internal drive temperature (˚C)
P00-21
CAN process data input
P00-22
CAN process data output
P00-23
Accumulated time with heatsink > 85˚C (Hours) Total accumulated hours and minutes of operation above heatsink temp of 85˚C.
P00-24
Accumulated time with drive internal temp >
80˚C (Hours)
P00-25
Estimated rotor speed (Hz)
P00-26
kWh meter / MWh meter
P00-27
Total run time of drive fans (Hours)
P00-28
Software version and checksum
P00-29
Drive type identifier
P00-30
Drive serial number
P00-31
Motor current Id / Iq
P00-32
Actual PWM switching frequency (kHz)
P00-33
Critical fault counter – O-I
P00-34
Critical fault counter – O-Volts
P00-35
Critical fault counter – U-Volts
P00-36
Critical fault counter – O-temp (h/sink)
6
P00-37
Critical fault counter – b O-I (chopper)
P00-38
Critical fault counter – O-hEAt (control)
P00-39
Modbus comms error counter
P00-40
CANbus comms error counter
P00-41
I/O processor comms errors
P00-42
Power stage uC comms errors
P00-43
Drive power up time (life time) (Hours)
P00-44
Phase U current offset & ref
P00-45
Phase V current offset & ref
P00-46
Phase W current offset & ref
P00-47
Index 1: Fire mode total active time
Index 2: Fire Mode Activation Count
P00-48
Scope channel 1 & 2
P00-49
Scope channel 3 & 4
P00-50
Bootloader and motor control
36 | Optidrive ODE-3 IP66 Outdoor Rated User Guide | Version 2.01
Explanation
100% = max input voltage.
100% = max input voltage.
Displayed in Hz if P-10 = 0, otherwise RPM.
Drive digital input status.
Displays value of the User PI output.
Measured DC bus ripple.
Value of RMS voltage applied to motor.
Internal DC bus voltage.
Temperature of heatsink in ˚C.
Not affected by resetting factory default parameters.
Run-time clock stopped by drive disable (or trip), reset on next enable only if a trip
occurred. Reset also on next enable after a drive power down.
Run-time clock stopped by drive disable (or trip), reset on next enable only if a trip
occurred (under-volts not considered a trip) – not reset by power down / power
up cycling unless a trip occurred prior to power down.
Displays most recent 4 trips with time stamp.
Run-time clock stopped on drive disable, value reset on next enable.
8 most recent values prior to trip, 256ms sample time.
8 most recent values prior to trip, 30s sample time.
8 most recent values prior to trip, 256ms sample time.
8 most recent values prior to trip, 22ms sample time.
8 most recent values prior to trip, 30 s sample time.
Actual internal ambient temperature in ˚C.
Incoming process data (RX PDO1) for CAN: PI1, PI2, PI3, PI4.
Outgoing process data (TX PDO1) for CAN: PO1, PO2, PO3, PO4.
Total accumulated hours and minutes of operation with drive internal ambient
above 80˚C.
In vector control modes, estimated rotor speed in Hz.
Total number of kWh / MWh consumed by the drive.
Time displayed in hh:mm:ss. First value displays time in hrs, press up to display
mm:ss.
Version number and checksum. "1" on LH side indicates I/O processor,
"2" indicates power stage.
Drive rating, drive type and software version codes.
Unique drive serial number.
Displays the magnetising current (Id) and torque current (Iq). Press UP to show Iq.
Actual switching frequency used by drive.
These parameters log the number of times specific faults or errors occur, and are
useful for diagnostic purposes.
Total lifetime of drive with power applied.
Internal value.
Internal value.
Internal value.
Total activation time of Fire Mode.
Displays the number of times Fire Mode has been activated.
Displays signals for scope channels 1 & 2.
Displays signals for scope channels 3 & 4.
Internal value.
