STI-24IO Interface

The STI-24IO interface for the Epsilon EP-I drives, see figure 116, allows access to all digital input and output signals. The
STI-24IO board mounts directly to the Epsilon EP-I drive Input/Output Connection (J3) and away from any high voltage
wiring.
Figure 116:
Dimensions of the STI-24IO Board
Note
Wiring should be done with consideration for future troubleshooting and repair. All wiring should be either color coded
and/or tagged with industrial wire tabs. Low voltage wiring should be routed away from high voltage wiring.
INPUTS
1
2
3
4
5
6
7
8
9
10
OUTPUTS
11
1
12
2
13
3
14
4
15
5
EN
6
7
+24V
8
0V
2.1
Options and Accessories
3.2
139
