Epsilon EP-I Indexing Drive and FM-2 Indexing Module Reference Manual

FM-2 Indexing Module Options

The following cables are used to connect various components to the MDS drive module and FM-2.
PE
Power Module Status
Logic Power
System Ready
Shunt Active
Shunt Fault
Over Temp
High VAC Input
System Ready
Shunt Active
Shunt Fault
Over Temp
High VAC Input
Drive Module Fault
AC Interlock
Ext Shunt Control
Fault Reset
Logic +24VDC
Power 24V rtn
PE
+
I/O 10-30 VDC
-
138
PE
FM-2
Inputs
1
2
3
4
5
6
7
8
Outputs
1
2
3
4
10 - 30 VDC +
-
RESET
J4
Serial
J5
Command
10-30
INPUT OUTPUT
VDC
J6
OIT-EN-232-XXX
or
OIT-EN-485-XXX
OIT-PC-232-XXX
and D9P-D9P adapter
Serial Cable, DDS-XXX,
Drive to Drive (J4 to J4)
Serial Cable, RS-232,
Drive to PC
TIA-XXX for DB-9 Pin Connector
Serial Cable, RS-485,
Drive to Screw Terminals
CO485-XXX
Command Cable, CMDX-003,
Base Drive to ECI-44
Command Cable, CMDO-XXX,
from lead encoder
Command Cable, CDRO-XXX,
Drive to AXIMA Classic or
other controller
