Epsilon EP-I Indexing Drive and FM-2 Indexing Module Reference Manual
3. Use the appropriate formula below to calculate the inertia.
For horizontal loads or counterbalanced vertical loads use the following formula:
Where:
IR = Inertia Ratio
R = ramp in ms/kRPM
Ta = (unsigned) percent continuous torque required during acceleration ramping (0 - 300)
Td = (unsigned) percent continuous torque required during deceleration ramping (0 - 300)
Vm = motor constant value from Table 18 below
For un-counter balanced vertical loads use the following formula:
Where:
IR = Inertia Ratio
R = ramp in ms/kRPM
Vm = motor constant value from the table below
Tau = (unsigned) percent continuous torque required during acceleration ramping while moving up (against the
constant force)
Tdu = (unsigned) percent continuous torque required during deceleration ramping while moving up (against the
constant force)
Tad = (unsigned) percent continuous torque required during acceleration ramping while moving down (aided by the
constant force)
Tdd = (unsigned) percent continuous torque required during deceleration ramping while moving down (aided by the
constant force)
Ramp Units Conversion
If you are using an external position controller to generate motion you may need to connect the ramp units as desired below.
Many position controllers define acceleration in units per sec
conversion when entering the information into the formula.
Conversion Formula:
Where:
MPK = accel ramp in ms/kRPM
RPSS = accel ramp in revolutions per second
Motor
MG-205
MG-208
MG-316
NT-320
106
• +
(R Vm (Ta Td))
=
IR
2000
• +
(R Vm (Tau Tud
=
IR
4000
6
10
=
MPK
•
(RPSS 60)
Drive Vm
4.77
5.11
EN-204
3.17
4.3
−
1
+ +
Tad Tdd))
−
1
2
. The formulas above use ms/kRPM. Make sure you make this
2
Percent Continuous/volt
RPM /volt (default scaled
(default scaled Torque
Command)
30
30
30
30
Actual Velocity)
600
600
600
600
