Epsilon EP-I Indexing Drive and FM-2 Indexing Module Reference Manual

Dimensions and Clearances

Epsilon EP-I Drive
The following table applies to the "A" as shown in the figure below.
144
Drive Model
EP202/204
EP206
5.94
[150.88]
5.22
[132.59]
DDC-RJ45
0.19
[4.8]
Dimension "A"
(shown in inches/mm)
2.11 [53.59]
2.82 [71.63]
2.5
[63.50]
.200
[5.08]
Cable
8.099
[205.72]
7.70
[195.58]
EIO Cable
0.75
[19.05]
"A"
1.20
[30.48]
0.45
(4X)Ø.219
[23.4]
[5.56]
