Epsilon EP-I Indexing Drive and FM-2 Indexing Module

Epsilon EP Drive Options

Windows 98, NT 4.0, 2000 or XP
Compatible Computer
(Customer Supplied)
CT-MME-POWER-CD
Contains PowerTools Pro
ESA HMI to Drive,
ESA-SP-485-xxx
Drive to Drive,
Drive RS485 to Drive RS485
DDC-RJ45-xxx
PC to Drive, PC RS232 to Drive RS485
Serial Interface Cable, CT-COMMS
Epsilon EP I/O Cable,
EIO26-xxx
INPUTS
1
2
3
4
5
6
7
8
9
10
OUTPUTS
11
1
12
2
3 13
4 14
15
5
EN
6
7
+24V
8
0V
STI-24IO
Drive Sync Out to
Drive Sync In Cable,
SNCDD-915-xxx
Drive Sync Out Cable,
SNCFLOA-xxx
Drive Sync Out to
FM-3/4 Module In Cable,
SNCMD-815-xxx
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15
Drive Sync Out Breakout Board,
STI-SNCOA

Options and Accessories

External Shunt Resistor,
SM-Heatsink DBR1
J8
Epsilon EP
reset
L1
L2
PE
R
S
T
+
_
3 MIN
EP204-I00-0000
9606XX-XX A1
SN 0610E014
J5 J10 J6
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15
Motor Feedback Breakout Board,
STI-ENC
Reference Manual
Drive Brake Relay,
BRM-1
Motor Power Cable, XTMDS-xxx
Motor Brake Cable, XTBMS-xxx
Motor Power Cable,
XCMDS-xxx or XCMDBS-XXX
NT or MG Motors
Motor Power Cable,
CMDS-xxx or CMMS-xxx*
Motor Brake Cable,
CBMS-xxx*
EZ Motors
Motor Power Cable,
PSBAFA-xxx, PBBAFA-xxx
Drive Sync In to Drive Sync Out Cable,
SNCDD-915-xxx
Drive Sync In Cable,
SNCFLI-xxx
Drive Sync In from
FM-3/4 Module Out Cable,
SNCMD-89-xxx
1 2 3 4
5 6 7 8
Drive Sync In Breakout Board,
STI-SNCI
XV Motors
Motor Feedback Cable, XEFTS-XXX
Motor Feedback Cable, XEFCS-XXX
NT or MG Motors
Motor Feedback Cable, EFCS-XXX*
EZ Motors
Motor Feedback Cable, SIBAAA-xxx
* Flex duty versions of these cables
are also available.
XV Motors
137
