Classifications

Class II Equipment

Type BF Applied part

Patient leakage current

Original Documentation

–
Vscan Extend User Manual
5721203-100 Rev. D
The following classifications are in accordance with the IEC/
EN 60601-1.
Type and degree of protection against electric shock:
• Vscan Extend has an internal battery which allows the
operation during AC power absence.
• The AC adapter is Class II.
• Vscan Extend has type BF Applied Part.
Vscan Extend main unit is rated IP33:
• 3: Protected against solid foreign objects of 2,5 mm Ø and
greater.
• 3: Protected against spraying water.
Vscan Extend probe (immersible portion) is IPX7.
EQUIPMENT in which protection against electric shock does not
rely on BASIC INSULATION only, but in which additional safety
precautions such as DOUBLE INSULATION or REINFORCED
INSULATION are provided, there being no provision for
protective earthing or reliance upon installation conditions.
TYPE BF APPLIED PART providing a specified degree of
protection against electric shock, with particular regard to
allowable LEAKAGE CURRENT.
Table i-2: Leakage Current
Normal mode
<100 microA
• The original document was written in English.
Single fault condition
<500 microA
i-5
