Appendix

Dimension and weight

Phased array transducer for deep scanning

Linear transducer for shallow scanning

7-2
System dimension and weight
• Main unit (approximately): 170 x 78 x 21 mm
• Weight (Main unit with Sector probe, without battery): 365g
• Weight (Main unit with Dual probe, without battery): 400g
• Battery Weight: 65g
Probe dimension and weight
• Dimension (L x B x H) Sector Probe:129 x 32 x 25 mm
• Dimension (L x B x H) Dual Probe: 129 x 39 x 28 mm
• Sector probe Weight (including cable): 85g
• Dual probe Weight (including cable): 120g
• Field-of-view for black and white imaging: up to 70 degrees
with maximum depth of 24 cm
• The color flow sector represents blood flow within an angle
of 40 degrees.
• Broad-bandwidth sector probe: from 1.7 to 3.8 MHz
• Footprint: 13 x 19 mm
• Field-of-view for black and white imaging: aperture width of
2.9 cm with maximum depth of 8 cm
• The color flow sector represents blood flow over image with
full aperture and entire depth.
• Broad-bandwidth linear probe: from 3.3 to 8.0 MHz
• Footprint: 9 x 35 mm

Specifications

–
Vscan Extend
5721203-100 Rev. D
User Manual
