Safety

Maximum probe temperature

Probe
Vscan Extend – configured with Sector probe:
Phased array transducer (G3S) for Deep scanning
Vscan Extend – configured with Dual probe:
Phased array transducer (G3S) for Deep scanning
Vscan Extend – configured with Dual probe:
Linear array transducer (G8L) allowing shallow
scanning
NOTE:
NOTE:
NOTE:
2-24
The table below indicates the maximum probe temperature.
Table 2-7: Maximum probe temperature
Measurement uncertainty and probe variation: 2 °C.
Lens temperature measured under following conditions per EN/
IEC 60601-2-37:
• Thermocouple was placed at the geometric center of the
lens.
• Thermal phantom at 33 °C (or 23 °C) for external probes.
(Temperature rise is measured and added to 33 °C if the
phantom is at 23 °C).
Thermal phantom made with tissue-mimicking material as
referenced in EN/IEC 60601-2-37.
• Probe placed upright in contact with above thermal
phantom.
• Auto-freeze capability is disabled.
• Lens temperature is monitored for 30 minutes.
Max Temp in deg C
(Simulated use)
39.7
41
39.1
Vscan Extend
Max Temp in deg C
(Still air)
43.1
42.6
42.3
–
