Privacy and Security

Overview

System interconnections

1. GE Health Cloud
2. Hospital Public Wireless infrastructure
3. Vscan Extend Device
4. Hospital Clinical Network
8-6

Network Connectivity

Network connection for the Vscan Extend is required by several
system features:
1. DICOM connectivity to other DICOM devices
2. Disk Management/Backup towards Windows share
3. Image/Video storage via the "JPG/MPEG" feature
The figure below shows the possible interconnections for the
Vscan Extend Ultrasound system. For a particular installation,
typically a subset of the interconnections is utilized.
Figure 8-1. Vscan Extend network diagram
5. PACS
6. Hospital Clinical Wireless infrastructure
7. Windows PC
Vscan Extend
–
User Manual
5721203-100 Rev. D
