Battery

Battery specification
–
Vscan Extend User Manual
5721203-100 Rev. D

Vscan Extend Battery

The Vscan Extend system is powered by a Li ION battery
(Model - U80395). The battery is not fully charged prior to
shipment. To maximize time of use, it is recommended to
recharge the battery before use for at least 1.5 hours. Establish
a routine for charging the battery to maximize system
availability.
The battery must be charged while housed in the Vscan Extend
or in the external battery charger.
The Li ION battery, used in Vscan Extend, with the battery code
is displayed below.
Figure 3-9. Vscan Extend battery
Table 3-7:
Items
Basic Voltage
Current
Vscan Extend Battery
Battery specification
Unit Value
mV 7400
mA 1150
Description
MAX
Avg 1C
3-15
