Lightspeed Flexmike User Manual page 7

FRONT PANEL CONTROLS & INDICATORS
POWER
1
2
1. POWER LIGHT: This light will turn blue when power is on.
2. POWER BUTTON: Press and hold this push button to turn the system power on or
off.
3. MICROPHONE VOLUME CONTROL: Controls the volume level of the microphones.
4. AUDIO IN VOLUME CONTROL: Controls the volume level of the audio source
connected to the audio input on back of the Multimike.
5. TONE CONTROL: Adjusts the audio tone adding more bass or treble for a more
rich or more crisp tone.
6. MIC 1: Microphone link and registration indicators.
a. Solid green indicates an audio link has been established.
b. Flashing amber indicates registration is in process.
MIC 2: Multimike systems do not use MIC 2 status lights.
7. SYSTEM ID LABEL: On bottom of unit (not shown) to identify it with registered
components.
6
MICROPHONE
1 2
MIN MAX
3
AUDIO IN TONE
MIN MAX TREBLE
4
2
BASS
7
2
5
7
