Lightspeed 955 Access Set Up And Daily Operation Instructions

955 ACCESS WITH ACTIVATE
DAILY OPERATION INSTRUCTIONS

ENSURE THE SYSTEM IS POWERED ON

1. Locate the 24V power supply and power cable and connect the AC power cord into the DC power
supply. Insert the DC connector into the DC Power jack on the back and plug the AC power cord
into an electrical outlet.
2. Press the Activate Station power button to power on the 955. When powered on, the blue LED on
the front of the 955 will glow.

USING THE FLEXMIKE

3. Remove the microphone from the charger and place the microphone around your neck.
Ensure the top of the microphone is at the collarbone.
4. Press the power/mute button. The teacher status will turn blue, indicating the
microphone is active.
5. Microphone volume may be adjusted at the microphone by using the Up/Down buttons on the side
of the Flexmike. It may also be adjusted by using the Microphone volume buttons on the front of the
Activate.

USE ACTIVATE STATION AS A WIRELESS AUDIO LINK

7. Plug your external audio equipment (for example, laptop), into one of the input jacks on
the back of the Activate labeled "Aux Input" using a 3.5mm patch cable.
8. Adjust volume at the audio source. If necessary, further volume adjustment may be
made using the Audio In volume buttons on the front of the Activate.
9. You may also connect an audio source using a 3.5mm patch cable to the Input jack on the side of a
second Flexmike.

CHARGE FLEXMIKE NIGHTLY

10. Place the Flexmike into the charger. The power button light will glow red and the Mic
status light will glow blue. When a Flexmike is fully charged, the power button light on
the mic will change to green.
For instructions on capturing audio and video using the Activate App, and for complete operating
instructions, go to www.lightspeed-tek.com/955-usermanual (or scan the 2D barcode below).
L ig h t spe e d Techn ol og ies
w w w. l i g h t s pe ed- tek .co m / 80 0.73 2.8999 / 503.684.5538
2
5
8
10
QS0542US01-3
1
Power / Mute
4
5
9
3
7
2
