Lightspeed Flexmike User Manual page 24

USING THE MEDIA CONNECTOR
The Media Connector, when paired together with the system, becomes the primary volume
control for the microphones and audio sources you've connected.
1. Plug the micro USB end of the power cable into the USB port on the back of the Media
Connector. Plug the other end of the cable into the USB1 power adaptor. Alternatively,
the USB cable could be plugged into a computer for power.
2. Connect the audio source(s) to the
Media Connector using the 3.5mm
cables provided.
3. Set the audio source volume to provide
sound through the audio system.
4. Use the AUDIO IN volume control on
the front of the Media Connector to
increase or decrease the audio source
sound level.
NOTE: When a Media Connector is paired with an Multimike, microphone volume and tone
control levels are locked out. Microphone volume and tone control levels default to the
Media Connector controls to avoid multiple control points for the same functions.
NORMALIZING AUDIO SOURCE VOLUME LEVELS
Use the Media Connector as the master audio volume control for audio sources. When
two or more audio sources are connected, you will need to normalize volume settings
by setting all connected audio sources to the same sound level while leaving the Media
Connector AUDIO IN volume control set to its center setting. The Media Connector is an
audio mixer using a master volume control to adjust the volume of all audio sources at
once. Use the following procedure to set audio source volumes:
1. Connect the multimedia audio sources to the Media Connector using the 3.5mm
cables provided.
2. Set the AUDIO IN volume control on the Media Connector to its center position.
3. Turn on an audio source that does not have an accessible audio level control. (DVD,
VCR player)
4. Adjust the Media Connector AUDIO IN volume control so the audio level playing
through the speaker is appropriate for the room.
5. Turn off the first audio source.
6. Turn on the second audio source. Use its volume control to balance the audio output
to the same audio level played through the speaker as the first source.
7. Repeat steps 5 and 6 for the remaining audio sources.
8. Now, the Media Connector's AUDIO IN volume can be used to increase or decrease the
volume level for all audio sources as desired.
24
TONE AUDIO OUT AUDIO IN
1 2 1 2 3
USB POWER
REGISTER
TREBLE BASS
5V/1.5A
4
