Connectors

Connectors connect the CPU card with other parts of the system.
Make sure all connectors are properly and firmly connected. Here is a
summary table shows you all connectors on the AX12270 Series.
Connectors
LAN Connector
Serial Port1 Connector
Serial Port2 Connector
LCD Backlight Connector
USB Port0 & Port1 Connector
LCD Connector
VGA/PS2 Connector
USB Port2 & Port3 Connector
Audio Connector
IDE Connector
COM1 Mode setting
COM1 Mode setting
PC104-B Slot
PC104-A Slot
PCI104 Slot
Digital I/O Connector
Front Panel Bezel Connector
SMBUS Connector
+12V & +5V Power Connector
+5V Standby & PS on Connector
CPU Fan Connector
Battery Connector
Jumpers and Connectors
AX12270 PC/104 Module Series User's Manual
Label
CN1
CN2
CN3
CN4
CN5
CN6
CN7
CN8
CN9
CN10
CN11
CN12
CN13
CN14
CN15
CN16
CN17
CN18
CN19
CN20
SBAT2
