Watdog Timer Setting
After the system stops working for a while, it can be auto-reset by the
Watchdog Timer. The integrated Watchdog Timer can be set up in the
system reset mode by program.
Timeout Value Range
1 to 255
Second
Program Sample
Watchdog Timer can be set to system reset after 5-second timeout.
2E, 87
2E, 87
2E, 07
2F, 08
2E, 29
2F, 20
2E F3
2F N
2E, F4
2F, M
2E, 30
2F, 01
Q
Watchdog Timer
AX12270 PC/104 Module Series User's Manual
A p p e n d i x A
Watchdog Timer
Enter the extended function mode
Enter the extended function mode
Logical Device 8
Set WDT Funtion Enable
0 or 4
M=00~FF
Activate
Quite
