AX12270 PC/104 Module Series User's Manual
2.4.1 LVDS Backlight Connector: CN3
The 7-pin inverter connector on the SBC is a Hirose connector. It is
strongly recommended to use the matching connector Hirose DF13-
7S-1.25C.
2.4.2 LVDS Flat Panel Connector: CN5
The LVDS connector on the SBC is a 40-pin connector. It is strongly
recommended to use the matching connector JST SHDR-40V-S-B.
Pin
1
VCCM
3
VCCM
5
VCCM
7
N.C.
9
GND
11 Channel B D3-
13 Channel B D3+
15 GND
17 Channel B CLK-
19 Channel B CLK+
21 GND
23 Channel A D0-
25 Channel A D0+
27 GND
29 Channel A D1-
12
Pin
Signal
1
12V
2
12V
3
5V
4
ENABLEI
5
GND
6
GND
7
GND
Signal
Pin
2
VCCM
4
VCCM
6
VCCM
8
N.C.
10 GND
12 Channel B D0-
14 Channel B D0+
16 GND
18 Channel B D1-
20 Channel B D1+
22 GND
24 Channel B D2-
26 Channel B D2+
28 GND
30 Channel A D3-
Jumpers and Connectors
Signal
