Rack Mechanical Drawing and Dimensions

Fig. 15
Fig. 15a
(ON)
Terminal Legend
3.125"
79.4mm
8.5"
215.9mm
0.75"
19.1mm
Altronix is not responsible for any typographical errors .
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
website: www .altronix .com | e-mail: info@altronix .com | Lifetime Warranty | Made in U .S .A .
IIMaximalDRackMountSeries
- 12 -
3 .25" x 19 .125" x 8 .5" (82 .6mm x 485 .8mm x 215 .9mm)
Fig. 15b
3-Wire
Line Cord
Rear
17.625"
447.7mm
Bottom
Front
19.125"
485.8mm
F11R
Fig. 15c
Removable Terminal
Block
Maximal Rack Access Power Controllers (PTC)
