Note: If LOCK is selected without a Preset configured, following screen is displayed:
Note: When Preset Lock is enabled, Clear Memory function is disabled and displays following Locked
message if attempted:
Note: When Preset Lock is enabled, Clear Cycle count function is disabled and displays Locked message
if attempted.
Preset Unlock
When Preset Lock is enabled, a password is required to access Configure menu. Refer to ControlTech™
Micro Calibration Manual for Configure password.
1. From target torque or angle screen, press and hold ENTER button for 3 seconds.
2. Highlight CONFIGURE
3. Press ENTER button to display Password screen.
4. Follow password entry procedure found in ControlTech™ Micro Calibration manual.
03
PSET 01
100.0
IN-LB
Preset Screen
Delete Presets
Delete Presets function allows user to delete all presets at once.
1. From Configure menu, use UP/DOWN buttons to highlight
ENTER button.
2. Delete Presets confirmation screen is displayed.
3. Use UP/DOWN buttons to select YES or NO selection.
4. Press ENTER button to accept selection and exit to Configure menu.
EXIT
MODE SETUP
PRESET LOCK
UP/DOWN buttons
MODE SETUP
PRESET LOCK
DELETE PRESETS
Note: If Delete Presets is selected without a Preset configured, following screen is displayed:
Job Mode
NO PRESETS
PRESS TO
CONT.
LOCKED
PRESS TO CONT.
menu selection using UP/DOWN buttons.
ENTER
EXIT
button
SET HEAD LENGTH
held
SHOW DATA
UP/DOWN buttons
LANGUAGE
SETTINGS
CONFIGURE
Delete Presets menu
ENTER DELETE PRESETS
button
YES
NO
UP/DOWN buttons
NO PRESETS
PRESS TO CONT.
ENTER PASSWD
ENTER
button
0 0 0 0 0
21

DELETE PRESET

selection then press
