Setting Target Tolerances
This function will allow user to set plus and minus tolerances for torque and angle targets.
Note: These tolerances are used for manual modes only. Preset tolerances are defined by Minimum
and Maximum values.
1. From Mode Setup menu, use UP/DOWN buttons to highlight tolerance selection to setup (TQ-%,
TQ+%, ANG-% ANG+%) then press ENTER button.
2. Tolerance screen is displayed.
3. Use UP/DOWN buttons to change tolerance value. Range is 0 to 10% (factory default for minus
tolerance is 0% and 4% for plus tolerance).
4. Press ENTER button to accept selection and exit to Mode Setup menu.
EXIT
TQ-% SETUP
TQ+% SETUP
UP/DOWN buttons
TQ+% SETUP
ANG-% SETUP
ANG+% SETUP
Note: Green progress lights turn on at target minus -% TOL.
Note: Red progress lights turn on above target plus +% TOL.
Note: Plus tolerance is added to minimum Preset value to define initial maximum value when a Preset
is first added.
Enable/Disable Torque THEN Angle Mode
This function will allow user to enable or disable Torque THEN Mode.
1. From Mode Setup menu, use UP/DOWN buttons to highlight
selection then press ENTER button.
2. TQ THEN ANGLE enable/disable screen is displayed.
3. Use UP/DOWN buttons to select ENABLE or DISABLE selection.
4. Press ENTER button to accept selection and exit to Mode Setup menu.
EXIT
TQ-% SETUP
TQ+% SETUP
UP/DOWN buttons
TQ-% SETUP
TQ+% SETUP
THEN DISABLED
Note: Menu selection indicates current configuration (ENABLED or DISABLED).
Torque THEN Angle Mode
Torque THEN Angle mode is setup by first setting a target torque and units then a target angle before
selecting Torque THEN Angle mode. In Torque THEN Angle mode, when applied torque reaches target
torque, wrench automatically switches to angle mode for angle measurement. Progress lights indicate
applied torque progress while torque is measured and angle when angle is measured. If torque is
below target torque when angle reaches target angle, green progress lights will not turn on and if angle
exceeds maximum angle, red progress lights turn on indicating a potential problem with fastener.
TORQUE -TOL%
ENTER
button
0
ANGLE +TOL%
ENTER
button
4
ENTER
TQ THEN ANGLE
button
ENABLE
DISABLE
UP/DOWN buttons
TQ THEN ANGLE
ENABLE
DISABLE
ENTER
TQ-% SETUP
button
TQ+% SETUP
THEN DISABLED
ENTER
TQ-% SETUP
button
TQ+% SETUP
THEN ENABLED
18
THEN DISABLED (factory default)
