Snap-On ControlTech Micro User Instructions page 20

1. From target torque screen, use UP/DOWN buttons to set target torque and UNITS button to select
torque measurement units then press ENTER button.
2. Angle target screen is displayed. Use UP/DOWN buttons to set target angle then press ENTER
button.
3. Torque THEN Angle mode screen is displayed.
4. Apply torque until target is reached then rotate wrench to target angle.
00
100.0
IN-LB
UP/DOWN buttons
Note: UNITS button can be used to select torque units while on Torque THEN Angle screen.
Note: Torque cycle is not recorded in memory unless both torque and angle reach targets.
Note: Red progress lights turn on if torque exceeds 110% of wrench full scale or if angle exceeds target
+ plus tolerance while in manual mode.
Note: Torque THEN Angle Presets are entered by pressing and holding Units button while on Torque
THEN Angle screen. MAXIMUM TORQUE defaults to full range plus 10%. Refer to "Adding a
Torque Preset" and "Adding an Angle Preset" in Basic section for parameter entry.
Enable/Disable Torque AND Angle Mode
This function will allow user to enable or disable Torque AND Mode.
1. From Mode Setup menu, use UP/DOWN buttons to highlight
selection then press ENTER button.
2. TQ AND ANGLE enable/disable screen is displayed.
3. Use UP/DOWN buttons to select ENABLE or DISABLE selection.
4. Press ENTER button to accept selection and exit to Mode Setup menu.
EXIT
TQ-% SETUP
TQ+% SETUP
UP/DOWN buttons
TQ+% SETUP
THEN DISABLED
AND DISABLED
Note: Menu selection indicates current configuration (ENABLED or DISABLED).
ENTER 00
button
45°
UP/DOWN buttons
ENTER
TQ AND ANGLE
button
ENABLE
DISABLE
UP/DOWN buttons
TQ AND ANGLE
ENABLE
DISABLE
ENTER
00
button
TQ: 100.0 IN-LB
THEN ANG: 45°
ENTER
TQ+% SETUP
button
THEN DISABLED
AND DISABLED
TQ+% SETUP
THEN DISABLED
AND ENABLED
19
AND DISABLED (factory default)
