Snap-On ControlTech Micro User Instructions page 10

00
100.0
IN-LB
Target Screen
00
100,0
IN-LB
3. To exit Main menu and return to target torque or angle screen, press ENTER button while
menu selection is highlighted.
Target Presets (PSET)
PSET function gives user ability to configure 50 preset target torque or target angle settings, each with
a target, minimum, maximum (over range) and batch count value. PSETs are stored in non-volatile
memory so that they are retained while power is off.
Note: After adding a Preset (see below), navigate between manual target torque, angle mode and PSET
screen by repeatedly pressing ENTER button. While PSET screen is displayed, press UP/DOWN
buttons to select additional configured PSETs.
Manual Target Torque Screen
100.0
IN-LB
Adding a Torque Preset
1. From manual target torque screen, select units of measure.
2. Press and hold UNITS button for 3 seconds.
3. ADD PRESET confirmation screen is displayed. Highlight
buttons then press ENTER button.
4. TARGET TORQUE screen is displayed. TARGET TORQUE is target value of fastener. Initial TARGET
TORQUE value is value from target torque screen. TARGET TORQUE can be set to any value within
wrench torque range by pressing UP/DOWN buttons. Once desired target torque value has been
set, press ENTER button.
5. MINIMUM TORQUE screen is displayed. MINIMUM TORQUE is value at which green progress lights,
audible alert and vibrator turn on. Initial MINIMUM TORQUE value is TARGET TORQUE value minus
negative torque tolerance (default 0%, see MODE SETUP in Advanced Configuration section).
MINIMUM TORQUE can be set to any value from TARGET TORQUE to wrench minimum torque
ENTER
EXIT
button
SET HEAD LENGTH
held
SHOW DATA
UP/DOWN buttons
CLEAR DATA
CYCLE COUNT
LANGUAGE
Manual Target Angle Screen
ENTER
00
button
90°
NO
Language Selection menu
ENTER
ENGLISH
button
FRANCAIS
ESPANOL
ENTER button
UP/Down buttons
Preset 3 Torque Screen
PSET 03
50.0
Preset 1 Torque Screen
00 ENTER
PSET 01
button
100.0
Preset 2 Angle Screen
PSET 02
90°
menu selection returns to main menu without adding a PSET.
9
Decimal Mark Selection menu
ENTER
DECIMAL MARK
button
COMMA (1,23)
POINT (1.23)
DECIMAL MARK
COMMA (1,23)
POINT (1.23)
ENTER
00
button
IN-LB
UP/Down buttons
ENTER
03
button
IN-LB
UP/Down buttons
04 ENTER
button
UP/Down buttons
YES menu selection using UP/DOWN
UP/DOWN buttons
EXIT
