Snap-On ControlTech Micro User Instructions page 13

00
PSET 02
92°
Preset Angle Screen
ENTER button
00
100.0
IN-LB
Target Torque Screen
Note: Pressing ENTER button while
Note: When a PSET is deleted, all other stored PSET's will retain their original PSET numbers. When a
new PSET is entered, it will be assigned first available PSET number in sequence.
 Advanced Settings
Accessing Advanced Settings
Advanced settings are accessed from
1. From target torque or angle screen, press and hold ENTER button for 3 seconds.
2. Highlight SETTINGS
3. Press ENTER button to display Settings menu.
Menu Selections:
 EXIT - Exits Settings menu and returns to target screen.
 SHOW INFO - Displays wrench operational information.
 SLEEP TIME - Displays power down interval setup screen.
 LCD CONTRAST - Displays LCD contrast setup screen.
 KEY BEEP - Displays button press beep enable/disable setup screen.
 AUTO BACKLIGHT - Displays auto backlight enable/disable screen to turn on backlight during
measurement.
 TOGGLE BACKLGHT - Displays BACKLIGHT button toggle or timeout enable/disable screen.
 VIBRATOR CONFIG - Displays vibrator ON/OFF configuration for when target reached.
 BATTERY TYPE – Displays the battery type selection screen.
4. To exit Settings menu and return to target torque or angle screen, press ENTER button while
menu selection is highlighted.
00
100.0
IN-LB
Target Screen
Note: All user configurable settings are stored in non-volatile memory and are retained while power is
off.
Show Info
Show Info menu selection displays wrench operational information.
1. From Settings menu, press ENTER button while
2. SHOW INFO screen is displayed.
UNIT
DELETE
button
held EDIT
EXIT
UP/DOWN buttons
DELETE
EDIT
EXIT
ENTER button
EXIT menu selection is highlighted will exit without deleting PSET.
SETTINGS
menu selection using UP/DOWN buttons.
ENTER
EXIT
button
SET HEAD LENGTH
held
SHOW DATA
UP/DOWN buttons
CYCLE COUNT
LANGUAGE
SETTINGS
menu selection on main menu.
EXIT
ENTER
button
SHOW INFO
SLEEP TIME
SHOW INFO
12
selection is highlighted.
EXIT
