Evaluation Board User Guide
DEFAULT OPERATION AND JUMPER SELECTION
SETTINGS
This board is shipped without a TCXO, low-pass filter, or a
VCO. Users must insert suitable components to complete a PLL.
Link positions are outlined in Table 1.
Table 1. Link Positions and Function
Link Position Options
LK1 A R1A
B RSET
LK2 A GND
B VDD
LK3 (V ) A 5V
DD
B 3V
LK4 (V ) A 5V
VCO
B 3V
LK5 (V ) A 5V
P
B 3V
Description
Not used
Normal operation
Hardware power-down
Normal operation
Not used
Normal operation
VCO supply 5 V
VCO supply 3 V
V supply 5 V
P
V supply 3 V
P
Rev. A | Page 5 of 24

SYSTEM DEMONSTRATION PLATFORM (SDP)

The system demonstration platform (SDP) is a series of control-
ler boards, interposer boards, and daughter boards that can be
used for easy low cost evaluation of Analog Devices, Inc.,
components and reference circuits. It is a reusable platform
whereby a single controller board can be reused in various
daughter board evaluation systems.
Controller boards connect to the PC via USB 2.0 and provide a
range of communication interfaces on a 120-pin connector.
The pinout for this connector is strictly defined. This 120-pin
connector's receptacle is on all SDP daughter boards, compo-
nent evaluation boards, and Circuits from the Lab™ reference
circuit boards. There are two controller boards in the platform:
the SDP-B, which is based on the Blackfin® ADSP-BF527, and
the SDP-S, which is a serial interface only controller board.
The SDP-S has a subset of the SDP-B functionality.
Interposer boards route signals between the SDP 120-pin con-
nector and a second connector. When the second connector is
also a 120-pin connector, the interposer can be used for signal
monitoring of the 120-pin connector signals. Alternatively, the
second connector allows SDP platform elements to be integrated
into a second platform, for example, the BeMicro SDK. More
information on the SDP can be found at www.analog.com/sdp.
