ADE9000 Technical Reference Manual
Addr. Name Bits
2
1
0
0x424 ADC_REDIRECT [31:21] RESERVED
[20:18] VC_DIN
[17:15] VB_DIN
[14:12] VA_DIN
[11:9]
[8:6]
[5:3]
[2:0]
Bit Name Settings Description
AVANL
AVARNL
AWATTNL
IN_DIN
IC_DIN
IB_DIN
IA_DIN
Rev. 0 | Page 77 of 86
This bit is set if the Phase A total apparent
energy is in no load.
This bit is set if the Phase A total reactive energy
is in no load.
This bit is set if the Phase A total active energy is
in no load.
Reserved.
VC channel data can be selected from all channels.
The bit descriptions for 000b through 110b match
VC_DIN. When the value is equal to 111b, then
000 IA ADC data.
001 IB ADC data.
010 IC ADC data.
011 IN ADC data.
100 VA ADC data.
101 VB ADC data.
110 VC ADC data.
111 VC ADC data.
VB channel data can be selected from all channels.
The bit descriptions for 000b through 110b match
VC_DIN. When the value is equal to 111b, then
111 VB ADC data.
VA channel data can be selected from all channels.
The bit descriptions for 000b through 110b match
VC_DIN. When the value is equal to 111b, then
111 VA ADC data.
IN channel data can be selected from all channels.
The bit descriptions for 000b through 110b match
VC_DIN. When the value is equal to 111b, then
111 IN ADC data.
IC channel data can be selected from all channels.
The bit descriptions for 000b through 110b match
VC_DIN. When the value is equal to 111b, then
111 IC ADC data.
IB channel data can be selected from all channels.
The bit descriptions for 000b through 110b match
VC_DIN. When the value is equal to 111b, then
111 IB ADC data.
IA channel data can be selected from all channels.
The bit descriptions for 000b through 110b match
VC_DIN. When the value is equal to 111b, then
111 IA ADC data.
UG-1098
Reset Access
0x0 R
0x0 R
0x0 R
0x0 R
0x7 R/W
0x7 R/W
0x7 R/W
0x7 R/W
0x7 R/W
0x7 R/W
0x7 R/W
