ADE9000 Technical Reference Manual
Address Name
0x030 BVAROS
0x031 BFWATTOS
0x032 BFVAROS
0x033 BIFRMSOS
0x034 BVFRMSOS
0x035 BVRMSONEOS
0x036 BIRMSONEOS
0x037 BVRMS1012OS
0x038 BIRMS1012OS
0x040 CIGAIN
0x041 CIGAIN0
0x042 CIGAIN1
0x043 CIGAIN2
0x044 CIGAIN3
0x045 CIGAIN4
0x046 CPHCAL0
0x047 CPHCAL1
0x048 CPHCAL2
0x049 CPHCAL3
0x04A CPHCAL4
0x04B CVGAIN
0x04C CIRMSOS
0x04D CVRMSOS
Description
Phase B total reactive power offset correction for the BVAR calculation.
Phase B fundamental active power offset correction for the BFWATT calculation.
Phase B fundamental reactive power offset correction for the BFVAR calculation.
Phase B current rms offset for the fundamental current rms BIFRMS calculation.
Phase B voltage rms offset for the fundamental voltage rms BVFRMS calculation.
Phase B voltage rms offset for the fast RMS½ BVRMSONE calculation.
Phase B current rms offset for the fast RMS½ BIRMSONE calculation.
Phase B voltage rms offset for the 10 cycle rms/12 cycle rms BVRMS1012 calculation.
Phase B current rms offset for the 10 cycle rms/12 cycle rms BVRMS1012 calculation.
Phase C current gain adjust.
Phase C multipoint gain correction factor. If multipoint gain and phase compensation
is enabled, with MTEN = 1 in the CONFIG0 register, an additional gain factor,
CIGAIN0 through CIGAIN5, is applied based on the CIRMS current rms amplitude
and the MTTHR_Lx and MTTHR_Hx register values.
Phase C multipoint gain correction factor. If multipoint gain and phase compensation
is enabled, with MTEN = 1 in the CONFIG0 register, an additional gain factor,
CIGAIN0 through CIGAIN5, is applied based on the CIRMS current rms amplitude
and the MTTHR_Lx and MTTHR_Hx register values.
Phase C multipoint gain correction factor. If multipoint gain and phase compensation
is enabled, with MTEN = 1 in the CONFIG0 register, an additional gain factor,
CIGAIN0 through CIGAIN5, is applied based on the CIRMS current rms amplitude
and the MTTHR_Lx and MTTHR_Hx register values.
Phase C Multipoint gain correction factor. If multipoint gain and phase compensation
is enabled, with MTEN = 1 in the CONFIG0 register, an additional gain factor,
CIGAIN0 through CIGAIN5, is applied based on the CIRMS current rms amplitude
and the MTTHR_Lx and MTTHR_Hx register values.
Phase C Multipoint gain correction factor. If multipoint gain and phase compensation
is enabled, with MTEN = 1 in the CONFIG0 register, an additional gain factor,
CIGAIN0 through CIGAIN5, is applied based on the CIRMS current rms amplitude
and the MTTHR_Lx and MTTHR_Hx register values.
Phase C multipoint phase correction factor. If multipoint phase and gain calibration is
disabled, with MTEN = 0 in the CONFIG0 register, the CPHCAL0 phase compensation
is applied. If multipoint phase and gain correction is enabled, with MTEN = 1, the
CPHCAL0 through CPHCAL4 value is applied, based on the CIRMS current rms
amplitude and the MTTHR_Lx and MTTHR_Hx register values.
Phase C multipoint phase correction factor. If multipoint phase and gain calibration is
disabled, with MTEN = 0 in the CONFIG0 register, the CPHCAL0 phase compensation
is applied. If multipoint phase and gain correction is enabled, with MTEN = 1, the
CPHCAL0 through CPHCAL4 value is applied, based on the CIRMS current rms
amplitude and the MTTHR_Lx and MTTHR_Hx register values.
Phase C multipoint phase correction factor. If multipoint phase and gain calibration is
disabled, with MTEN = 0 in the CONFIG0 register, the CPHCAL0 phase compensation
is applied. If multipoint phase and gain correction is enabled, with MTEN = 1, the
CPHCAL0 through CPHCAL4 value is applied, based on the CIRMS current rms
amplitude and the MTTHR_Lx and MTTHR_Hx register values.
Phase C multipoint phase correction factor. If multipoint phase and gain calibration is
disabled, with MTEN = 0 in the CONFIG0 register, the CPHCAL0 phase compensation
is applied. If multipoint phase and gain correction is enabled, with MTEN = 1, the
CPHCAL0 through CPHCAL4 value is applied, based on the CIRMS current rms
amplitude and the MTTHR_Lx and MTTHR_Hx register values.
Phase C multipoint phase correction factor. If multipoint phase and gain calibration is
disabled, with MTEN = 0 in the CONFIG0 register, the CPHCAL0 phase compensation
is applied. If multipoint phase and gain correction is enabled, with MTEN = 1, the
CPHCAL0 through CPHCAL4 value is applied, based on the CIRMS current rms
amplitude and the MTTHR_Lx and MTTHR_Hx register values.
Phase C voltage gain adjust.
Phase C current rms offset for the CIRMS calculation.
Phase C voltage rms offset for the CVRMS calculation.
Rev. 0 | Page 55 of 86
UG-1098
Reset Access
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
0x00000000 R/W
