Address Name
0x25A CVRMSONE
0x25B CIRMS1012
0x25C CVRMS1012
0x25D CMTREGION
0x265 NI_PCF
0x266 NIRMS
0x267 NIRMSONE
0x268 NIRMS1012
0x269 ISUMRMS
0x26A VERSION2
0x2E5 AWATT_ACC
0x2E6 AWATTHR_LO
0x2E7 AWATTHR_HI
0x2EF AVAR_ACC
0x2F0 AVARHR_LO
0x2F1 AVARHR_HI
0x2F9 AVA_ACC
0x2FA AVAHR_LO
0x2FB AVAHR_HI
0x303 AFWATT_ACC
0x304 AFWATTHR_LO
0x305 AFWATTHR_HI
0x30D AFVAR_ACC
0x30E AFVARHR_LO
0x30F AFVARHR_HI
0x317 AFVA_ACC
0x318 AFVAHR_LO
0x319 AFVAHR_HI
0x321 BWATT_ACC
0x322 BWATTHR_LO
Description
Phase C voltage fast RMS½ calculation, one cycle rms updated every half cycle.
Phase C current fast 10 cycle rms/12 cycle rms calculation. The calculation is
performed over 10 cycles if SELFREQ = 0 for a 50 Hz network or over 12 cycles if
SELFREQ = 1 for a 60 Hz network, in the ACCMODE register.
Phase C voltage fast 10 cycle rms/12 cycle rms calculation. The calculation is
performed over 10 cycles if SELFREQ = 0 for a 50 Hz network or over 12 cycles if
SELFREQ = 1 for a 60 Hz network, in the ACCMODE register.
If multipoint gain and phase compensation is enabled, with MTEN = 1 in the
CONFIG0 register, these bits indicate which CIGAINx and CPHCALx is currently
being used.
Instantaneous neutral current channel waveform processed by the DSP at 8 kSPS.
Neutral current filter-based rms value.
Neutral current fast RMS½ calculation, one cycle rms updated every half cycle.
Neutral current fast 10 cycle rms/12 cycle rms calculation. The calculation is
performed over 10 cycles if SELFREQ = 0 for a 50 Hz network or over 12 cycles if
SELFREQ = 1 for a 60 Hz network, in the ACCMODE register.
Filter-based rms based on the sum of IA + IB + IC ± IN.
This register indicates the version of the metrology algorithms after the user
writes run = 1 to start the measurements.
Phase A accumulated total active power, updated after PWR_TIME 8 kSPS samples.
Phase A accumulated total active energy, LSB. Updated according to the settings
in the EP_CFG and EGY_TIME registers.
Phase A accumulated total active energy, MSB. Updated according to the settings in
the EP_CFG and EGY_TIME registers.
Phase A accumulated total reactive power, updated after PWR_TIME 8 kSPS samples.
Phase A accumulated total reactive energy, LSB. Updated according to the settings in
the EP_CFG and EGY_TIME registers.
Phase A accumulated total reactive energy, MSB. Updated according to the settings
in the EP_CFG and EGY_TIME registers.
Phase A accumulated total apparent power, updated after PWR_TIME 8 kSPS samples.
Phase A accumulated total apparent energy, LSB. Updated according to the settings
in the EP_CFG and EGY_TIME registers.
Phase A accumulated total apparent energy, LSB. Updated according to the settings
in the EP_CFG and EGY_TIME registers.
Phase A accumulated fundamental active power, updated after PWR_TIME
8 kSPS samples.
Phase A accumulated fundamental active energy, LSB. Updated according to the
settings in the EP_CFG and EGY_TIME registers.
Phase A accumulated fundamental active energy, MSB. Updated according to the
settings in the EP_CFG and EGY_TIME registers.
Phase A accumulated fundamental reactive power, updated after PWR_TIME 8 kSPS
samples.
Phase A accumulated fundamental reactive energy, LSB. Updated according to
the settings in the EP_CFG and EGY_TIME registers.
Phase A accumulated fundamental reactive energy, MSB. Updated according to
the settings in the EP_CFG and EGY_TIME registers.
Phase A accumulated fundamental apparent power, updated after PWR_TIME 8 kSPS
samples.
Phase A accumulated fundamental apparent energy, LSB. Updated according to
the settings in the EP_CFG and EGY_TIME registers.
Phase A accumulated fundamental apparent energy, MSB. Updated according to
the settings in the EP_CFG and EGY_TIME registers.
Phase B accumulated total active power, updated after PWR_TIME 8 kSPS samples.
Phase B accumulated total active energy, LSB. Updated according to the settings
in the EP_CFG and EGY_TIME registers.
Rev. 0 | Page 58 of 86
ADE9000 Technical Reference Manual
Reset Access
0x00000000 R
0x00000000 R
0x00000000 R
0x0000000F R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x0000000C R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
0x00000000 R
