During a SPI read operation, the LAST_DATA_16 and
LAST_DATA_32 registers are updated within two master clocks
after the CMD_HDR has been received. If a command to read
the LAST_CMD, LAST_DATA_16, or LAST_DATA_32 registers
is received, these three registers are not updated.
Note that the LAST_DATA_16 and LAST_DATA_32 registers
are not updated after a SPI burst read operation; these are the
cases in Table 20 where next address is written.
On a write operation, LAST_DATA_16 and LAST_DATA_32
are not updated until all 16 bits or 32 bits of the write data have
been received. Note that on a write register operation, the
addressed register is not written until all 16 bits or 32 bits are
received, depending on the length of the register.
Note that when the LAST_CMD, LAST_DATA_16, and LAST_
DATA_32 registers are read, their values remain unchanged.

CRC OF CONFIGURATION REGISTERS

The configuration register CRC feature in the
many register values. It also optionally includes 15 registers that
are individually selectable in the CRC_OPTEN register.
This feature runs as a background task; it takes 10.8 ms to
calculate the configuration register CRC. The result is stored in
the CRC_RSLT register. If any of the monitored registers change
value, the CRC_RSLT changes as well, and the CRC_CHG bit in
the STATUS 1 register is set; this can also be configured to
generate an interrupt on IRQ1 .
After configuring the ADE9000
to calibrate the measurements (such as xIGAIN or xVGAIN, for
example), the configuration register CRC calculation can be
started by writing the FORCE_CRC_UPDATE bit in the
CRC_FORCE register. When the calculation is complete, the
CRC_DONE bit is set in the STATUS1 register.
The method used for calculating the configuration register
CRC is also based on the CRC-16-CCITT algorithm. The most
significant byte of each register is introduced into the LFSR first,
without bit reversal.
ADE9000 monitors
and writing the required registers
The order in which the registers are calculated is given in Table 21,
with the lowest register introduced first. Note that 32-byte registers
have four bytes introduced into the LFSR, and 16-byte registers
have two bytes introduced into the LFSR.
Table 21. Order of Registers Included in Configuration
Register CRC
Register Addresses
0x01 to 0x18
0x21 to 0x38
0x41 to 0x58
0x60 to 0x73
0x409
0x40F
0x420 to 0x422
0x424
0x470 to 0x475
0x480 to 0x481
0x490 to 0x497
0x499
0x4AF to 0x4B2
0x425
0x4B8 to 0x4B9
0x47D
0x478 to 0x479
0x4EF
0x4BA
0x47E
0x00
0x20
0x40
0x4B6
0x4BF
0x4B5
Rev. 0 | Page 35 of 86
UG-1098
Register Length (Bits)
32
32
32
32
32
32
32
32
32
16
16
16
16
32
16
32
32
16
16
32
32
32
32
16
16
16
