Analog Devices ADE9000 Technical Reference Manual page 74

UG-1098
Addr. Name Bits
8
7
6
5
4
3
2
1
0
0x407 EVENT_MASK [31:17] RESERVED
16
15
14
13
12
11
10
9
Bit Name Settings Description
ZXTOVC
ZXTOVB
ZXTOVA
VAFNOLOAD
RFNOLOAD
AFNOLOAD
VANLOAD
RNLOAD
ANLOAD
DREADY
VAFNOLOAD
RFNOLOAD
AFNOLOAD
VANLOAD
RNLOAD
ANLOAD
REVPSUM4
Rev. 0 | Page 74 of 86
ADE9000 Technical Reference Manual
Set this bit to enable an interrupt when there is a
zero-crossing timeout on Phase C. This means
that a zero-crossing on the Phase C voltage is
missing.
Set this bit to enable an interrupt when there is a
zero-crossing timeout on Phase B. This means
that a zero-crossing on the Phase B voltage is
missing.
Set this bit to enable an interrupt when there is a
zero-crossing timeout on Phase A. This means
that a zero-crossing on the Phase A voltage is
missing.
Set this bit to enable an interrupt when one or
more phase fundamental apparent energy
enters or exits the no load condition.
Set this bit to enable an interrupt when one or
more phase total reactive energy enters or exits
the no load condition.
Set this bit to enable an interrupt when one or
more phase fundamental active energy enters or
exits the no load condition.
Set this bit to enable an interrupt when one or
more phase total apparent energy enters or exits
the no load condition.
Set this bit to enable an interrupt when one or
more phase total reactive energy enters or exits
the no load condition.
Set this bit to enable an interrupt when one or
more phase total active energy enters or exits
the no load condition.
Reserved.
Set this bit to enable the EVENT pin to go low
when new waveform samples are ready. The
update rate depends on the data selected in
the WF_SRC bits in the WFB_CFG register.
Set this bit to enable the EVENT pin to go low
when one or more phases of fundamental
apparent energy accumulation goes into no load.
Set this bit to enable the EVENT pin to go low
when one or more phases of fundamental
reactive energy accumulation goes into no load.
Set this bit to enable the EVENT pin to go low
when one or more phases of fundamental active
energy accumulation goes into no load.
Set this bit to enable the EVENT pin to go low
when one or more phases of total apparent
energy accumulation goes into no load.
Set this bit to enable the EVENT pin to go low
when one or more phases of total reactive
energy accumulation goes into no load.
Set this bit to enable the EVENT pin to go low
when one or more phases of total active energy
accumulation goes into no load.
Set this bit to enable the EVENT pin to go low to
indicate if the last CF4 pulse was from negative
energy. This bit is updated when a CF4 pulse is
output, when the CF4 pin goes from high to low.
Reset Access
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
0x0 R/W
